ZRP RODS – CONNECTING ROD SET ZRP 1.4 TJET – 1.4 MULTIAIR

The Opel 1.6L and 1.8L A16/A18 I-Beam connecting rods are made from high-strength 4340 steel and are designed for high performance, extreme durability, and extra rigidity. These rods have a tapered pin end, making them compatible with OEM pistons. The bushings are made of AMPCO 18 material for excellent wear and fatigue resistance and feature a radial groove for the oil reservoir. They are shot peened to relieve material stress and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bending and torsion are strictly controlled. Each connecting rod includes ARP 2000 cap fasteners rated at 220,000 psi. Optional ARP L19 material rated at 260,000 psi is available as an upgrade. The entire kit is supplied with ARP moly and complete installation instructions.
Additional MachiningTapered Pin End – Fits OEM PistonsCentering Sleeves for a Perfect Fit and Accurate ReassemblyRibbed Cap Relief for Improved Big End Integrity in Extreme ApplicationsThrust Face Grooves for Weight ReductionTechnical Features of ZRP Connecting RodsTwo-Piece Forging for High StrengthShot Peening for Improved Fatigue LifeMagnaflux Inspection ensures the consistency of the forged material meets our high quality standardsDouble-Ribbed Caps for Increased SupportHeat Treated Multi-stage for maximum strength, dimensional stability, and fatigue resistance.CNC-machined for superior tolerances, accurate to 0.0002″Center-to-center is held to a tolerance of 0.001″Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rodsOptimal balance for weight-matched sets of ± 1 gramAdditional InformationEngine Number Models X16XE, X16XEL, C16NZ, C16N2Application 1.4L and 1.6LNotes: Tapered pin end / also fits OEM pistonsBolt Size 3/8”I-BEAM ShapeLength (CC) 129.75Pin Size 18.00Big Bore 46.00BE Width 21.90Weight 403 gSET of 4Clamping Grade ARP2000Standard SeriesWeight 403 g
