ZRP RODS – ALFA 159 / BRERA / 4C / GIULIETTA 1750CC TBI I-BEAM CONNECTING RODS

The I-Beam “Heavy Duty” series connecting rods for the Alfa 1750cc TBI are designed for high-horsepower/boost applications. They are constructed from the finest raw materials, high-strength 4340 steel, with a specially optimized shape for high performance and extreme durability. They feature “straight-cut” pin ends for increased durability, so they can only be used with aftermarket pistons. The bushings are made from AMPCO 18 material for excellent wear and fatigue resistance and have a radial groove that serves as an oil reservoir. They are shot-peened to relieve material stress and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bending and torsion are strictly controlled. Each connecting rod includes ARP 2000 plug fasteners rated at 220,000 psi, with optional ARP L19 material rated at 260,000 psi available as an upgrade, and the entire kit comes with ARP moly and complete installation instructions.
Additional MachiningStraight Cut Pin End – Suitable for Aftermarket PistonsCentering Sleeves for a Perfect Fit and Accurate ReassemblyRibbed Cap Relief for Improved Big End Integrity in Extreme ApplicationsThrust Face Grooves for Weight ReductionTechnical Features of ZRP Connecting RodsI-Shape for Extra RigidityTwo-Piece Forging for High StrengthShot Peening for Improved Fatigue LifeMagnaflux Inspection ensures the consistency of the forged material meets our high quality standardsDouble-Ribbed Caps for Greater SupportMulti-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance.CNC machining for superior tolerances, accurate to 0.0002″Center-to-center is held to a tolerance of 0.001″Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rodsOptimal balance for weight-matched sets of ± 1 gramThese connecting rods have a maximum power output of 200 hp per cylinder with ARP 2000 fasteners and 240 hp with ARP L19 fasteners.Additional informationEngine number4C, 940B2000, 940A1000, 939B1000, 960A1000Application1.8L TBIClipboardNon-tapered pin endBolt size3/8″ShapeI-BeamLength (CC)148.04Pin size22.00Big bore51.37B.E Width21.94Weight Gr.498Set of4Fastener GradeARP2000SeriesHeavy DutyWeight498
