ZRP RODS – CONNECTING ROD SET AUDI 1.8L 20V TURBO / 2.0L TSI EA113 HD SERIES

The Suzuki 1.6L Liana/Swift M16A H-Beam connecting rods are machined from high-strength 4340 steel and are designed for high performance and extreme durability. The bushings are made from aluminum-silicon/bronze and have a radial groove that serves as an oil reservoir. These connecting rods feature a ribbed pin end, which minimizes pin end distortion under heavy inertial loads while saving excess weight. They are shot peened to relieve stress from the material and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bending and torsion are strictly controlled. Each connecting rod includes ARP 2000 cap fasteners rated at 220,000 psi. Optional ARP Custom Age 625 material rated at 280,000 psi is available as an upgrade. The entire kit comes with ARP moly and complete installation instructions.
Additional machiningCentering sleeves for a perfect fit and accurate reassemblyEmbossed cap with edge for improved big end integrity in extreme applicationsThrust face grooves for weight reductionTechnical features of ZRP connecting rodsTwo-piece forging for high strengthAluminum-silicon/bronze bushing with radial grooveShot peening for improved fatigue lifeMagnaflux Inspection ensures that the consistency of the forged material meets our high quality standardsDouble-rib caps for increased supportTreatment Multi-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance.CNC machined for superior tolerances, accurate to 0.0002″Center-to-center is held to a tolerance of 0.001″Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rodsOptimal balance for weight-matched sets of ± 1 gramAdditional InformationEngine Number M16AApplication 1.6L M16Bolt Size 5/16”Shape H-BEAMLength (CC) 153.16Pin Size 20.00Big Bore 45.00Width BE 23.84Weight 412 gSet of 4ARP2000 fastening gradeStandard SeriesWeight: 412g
