ZRP RODS – SUZUKI LIANA / SWIFT M16A H-BEAM CONNECTING RODS SET

The I-Beam connecting rods for the VW 2.0L 16v (ABF) are made from high-strength 4340 steel and are designed for high performance, extreme durability, and extra rigidity while also being lightweight. The bushings are made from AMPCO 18 material for excellent wear and fatigue resistance and feature a radial oil reservoir groove. They are shot peened to relieve stress from the material and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bend and twist are tightly controlled. Each rod includes ARP 2000 cap fasteners rated at 220.00 psi; optional ARP L19 material is available as an upgrade. The connecting rod kit comes with ARP moly and complete installation instructions.
Additional MachiningCentering sleeves for a perfect fit and accurate reassemblyEmbossed cap with lip for improved big end integrity in extreme applicationsThrust face grooves for weight reductionTechnical Features of ZRP Connecting RodsTwo-piece forging for high strengthShot peening for improved fatigue lifeMagnaflux Inspection ensures that the consistency of the forged material meets our high quality standardsDouble-rib caps for increased supportMulti-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance.CNC-machined for superior tolerances, accurate to 0.0002″Center-to-center is held to a tolerance of 0.001″Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rodsOptimal balance for weight-matched sets of ± 1 gramThe maximum power of these connecting rods is 155 hp per cylinder with ARP 2000 fasteners and 175 hp with ARP L19 fasteners.Additional information Engine number ABF, 2E Application 2.0L 16v Clipboard Lightweight design – N/A use Bolt size 3/8″ Shape I-BEAM Length (CC) 159.00 Pin size 9.00pm Big Bore 50.60 BE Width 24.89 Weight Gr. 566 SET of 4 Degree of fastening ARP2000 Series Standard series Weight 566
