ZRP RODS – SUBARU EJ20 / EJ205 / EJ25 I-BEAM CONNECTING ROD SET

The I-Beam connecting rods for the Audi/VW 2.0L TFSI EA888 Gen.2 (chain-driven) are made from high-strength 4340 steel and are designed for high performance, extreme durability, and extra rigidity. They are “rifle drilled” as per OEM standards to improve oiling on the pin end. These feature a “straight cut” pin end for increased durability, so they can only be used in conjunction with aftermarket pistons. The bushings are made from AMPCO 18 material for excellent wear and fatigue resistance and have a radial oil reservoir groove. They are shot peened to relieve stress from the material and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bending and torsion are strictly controlled. Each rod includes ARP 2000 cap fasteners rated at 220,000 psi, optional ARP L19 material rated at 260,000 psi is available as an upgrade, and the entire kit comes with ARP moly and complete installation instructions.
Additional MachiningRifle drilled for maximum lubrication to increase wrist pin longevity”Straight cut” pin end: suitable for aftermarket pistons.Centering sleeves for a perfect fit and accurate reassemblyRibbed cap relief for improved big end integrity in extreme applicationsThrust face grooves for weight reductionTechnical Features of ZRP Connecting RodsI-Shape for extra rigidityTwo-piece forging for great strengthShot peening for improved fatigue lifeMagnaflux Inspection Ensures the consistency of the forged material meets our high quality standards.Double-rib end caps for increased support.Multi-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance.CNC-machined for superior tolerances, accurate to 0.0002″.Center-to-center is held to a tolerance of 0.001″.Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rods.Optimal balance for weight-matched sets of ± 1 gram.Additional InformationEngine Number 2011-Current: CCTA, CCZA, CCZB, CBF, CAEB, CAEA, CDNB, CDNC, CJXC, CCHA, CHHB, MQBEngine Application: 2.0L TFSI/TSINotes: Non-tapered / rifled stud endBolt Size: 3/8″I-BEAM ShapeLength (CC) 144.00Stud Size: 11.00pmBig Bore: 50.60BE Width: 21.85Weight: 508 gSET of 4Fastening Grade: ARP2000Standard SeriesWeight: 508 g
