ZRP RODS – SET CONNECTING RODS CITROEN C2 1.6L 16V TU5J94 / PEUGEOT 106 1.6L 8V TU5J2 H-BEAM

The I-Beam Series “Heavy Duty” connecting rods for Audi/VW 2.0L TFSI (chain-driven) are intended for high-horsepower/boost applications. Manufactured from the finest raw materials, 4340 high-strength steel, with a specially optimized shape for high performance and extreme durability. They feature “straight cut” pin ends for increased durability, so they can only be used in conjunction with aftermarket pistons. The bushings are made from AMPCO 18 material for excellent wear and fatigue resistance and have a radial groove that serves as an oil reservoir. They are shot peened to relieve stress from the material and multi-stage heat treated to increase rigidity. Tight manufacturing tolerances ensure a perfect fit while optimizing oil clearances. Bending and torsion are strictly controlled. Each rod includes ARP 2000 cap fasteners rated at 220,000 psi, optional ARP L19 material rated at 260,000 psi is available as an upgrade, and the entire kit comes with ARP moly and complete installation instructions.
Additional MachiningStraight Cut Pin End – Suitable for Aftermarket PistonsCentering Sleeves for a Perfect Fit and Accurate ReassemblyEmbossed Cap with Edge for Improved Big End Integrity in Extreme ApplicationsThrust Face Grooves for Weight ReductionTechnical Features of ZRP Connecting RodsI-Shape for Extra RigidityTwo-Piece Forging for High StrengthShot Peening for Improved Fatigue LifeMagnaflux Inspection ensures the consistency of the forged material meets our high quality standardsCaps Double rib for increased supportMulti-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance.CNC-machined for superior tolerances, accurate to 0.0002″Center-to-center is held to a tolerance of 0.001″Finite Element Analysis (FEA) Computer-generated stress analysis of connecting rodsOptimal balance for weight-matched sets of ± 1 gramThe maximum power of these connecting rods is 200 hp per cylinder with ARP 2000 fasteners and 240 hp with ARP L19 fasteners.Additional InformationApplication: 2.0L TFSI/TSI EngineNotes: Non-tapered stud endBolt Size: 3/8″I-BEAM ShapeLength (CC) 144.00Stud Size: 10.00pmBig Bore: 50.60BE Width: 21.90Weight: 492 gSet of 4Fastening Grade: ARP2000Heavy Duty SeriesWeight: 492 g
