TURBOSYSTEM – UNIVERSAL TURBOCHARGER HTX3057B2V

SPECIFICATIONS
SAME SPECIFICATIONS AS THE HTX3057B2, EXCEPT THE TURBINE FLANGE IS REPLACED WITH A 2.25″ V-BAND CONNECTION.HIGH-PERFORMANCE TURBOCHARGER DESIGNED FOR HEAVY LOADS AND HIGH TEMPERATURES. TWO COMPRESSOR SIDE OUTLET OPTIONS: 90° AND STRAIGHT FOR EASIER CONNECTION. DUAL CERAMIC BALL BEARINGS AND A BILLET ALUMINUM COMPRESSOR WHEEL MAKE IT A DURABLE AND EFFICIENT SOLUTION FOR MOTORSPORTS USE.POWER RANGE: 400-500+ HP;THIS TURBOCHARGER COMES WITH 2 SETS OF V-BANDS (FOR TURBINE FLANGE AND EXHAUST).COMPRESSOR SIDE:COMPRESSOR HOUSING WITH GUARD AND PORTS;COMPRESSOR WHEEL: BLADES REINFORCED 57/71 MM 9+0 INTERNALS MACHINED FROM SOLID ALUMINUM;INTAKE:STRAIGHT COMPRESSOR HOUSING – 63 MM;(2.5″) 90° ELBOW COMPRESSOR HOUSING – 76 MM (3″);AIR OUTLET: 51 MM (2″);CORE:BEARINGS: DOUBLE CERAMIC BALL BEARINGS;COOLING: WATER COOLING WITH 2 M14X1.5 PORTS;LUBRICATION: AN4 OIL INLET WITH OIL RESTRICTOR INTEGRATED;TURBINE SIDE:CASE: SINGLE-SLIP, 10 CM2 AR: 0.73;TURBINE WHEEL: CUSTOM-DESIGNED 60/55MM 9-BLADEFLANGE: SINGLE-SLIP WITH 2.25″ V-BAND;EXHAUST CONNECTION: 3″ V-CLAMP;NOT SURE WHICH TURBOCHARGER TO CHOOSE? CHECK OUT OUR HTX TURBO SPECS PAGE FOR A QUICK COMPARISON.MORE INFORMATION ON OPTIONAL EXTRAS:OIL DRAIN FLANGE PAGE: HTTPS://WWW.TURBOSYSTEMS.INFO/PRODUCT-PAGE/HTX-TURBO-OIL-DRAIN-FLANGE
